Features of the whole machine
1. Servo pressure-free leading edge paper feeding system.
2. Computer control of the whole machine, simple operation, scanning code and changing bill with one key.
3. The width of the slotting knife is 7mm, which is a plate- free die-cutting blade with long service life.
4.The slotting phase servo is automatically adjusted, and the slotting cutter wheel is provided with an automatic zero structure.
5. Infinite length design, both large and small cardboard can be used.
型号MODEL | MODEL | AXD-033 |
开发系统 | Development system | LV02.0版（全电脑系统+扫描系统） |
机器内侧宽度 | Inside width of machine | 2800mm |
最高生产速度 | Production speed | 20-150m/min （依照尺寸大小调速） |
最大通纸量(WxL) | Maximum paper throughput (WxL) | 2500*unlimited |
最小出纸量(WxL) | Minimum output (WxL) | 590*230mm |
适应进纸厚度 | Adapt to paper thickness | 2-10mm |
最小箱高 | Minimum box height | 不变速170mm变速60-170mm |
最大切角宽度 | Maximum chamfer width | 45mm |
开槽宽度 | Slotting width | 7mm |
最大开槽深度 | Maximum groove depth | 500mm |
最小开槽间隔(反刀) | Minimum slotting interval (reverse knife) | 230X60X230X60mm |
刀盘组数 | Number of cutter heads | 5组 |
总马力 | Power | 45kw |
外形尺寸 | Dimensions | 4500*2600*1600mm |
机械重量 | Mechanical weight | 6000kgs |
